SMP 300 Series • Front Panel Operations 48
Status Menu
The STATUS menu contains read‑only
submenus that show the current unit status
including active alarms, recording file names,
free space and total internal and external
drive capacity, and bit rates for archive and
confidence streams.
• ALARM STATUS — Scroll through the active
alarms. If no alarms are present, it shows
None.
• ARCHIVE — Displays filenames currently
being written to or the last file created.
If the filename is longer than sixteen
characters, the filename scrolls. It shows
N/A if no new or current recordings are
present.
NOTE: A non‑ASCII character in a
filename is displayed as a white block.
• DRIVE SPACE — Indicates the free and total
space on the internal hard drive and the
selected USB drive. The capacity is shown
in three digits with two decimals in either
MB or GB.
• SELECTED VOLUME NAME — Displays the
size and free space on a connected USB
drive.
NEXT
NEXT
NEXT
NEXT
NEXT
(Could say USBREAR if
selected in web pages)
NEXT
CHA BR 5000 kpbs
MULTI RTP/UDP
EXIT MENU?
PRESS NEXT
STATUS
[ARCH] BR 5000 kbps
MULTI TS/RTP
NEXT
CHA BR 5000 kpbs
MULTI RTP/UDP
CONF BR 350 kbps
UNI RTP/UDP
MENUMENU
NEXT
ALARM STATUS
[NONE, HDCP, VIDEO...]
ARCHIVE
[...FILENAME...]
DRIVE SPACE INT
[FREE/TOTAL][GB]
SELECTED USBFRONT
[FREE/TOTAL] [GB]
SELECTED VOLNAME
[FREE/TOTAL][GB]
• OUTPUT STREAM — Displays the video bit rate and protocol of the output stream.
Press NEXT to return to the STATUS menu.
Exit Menu
From this submenu, press MENU to return to the PRESETS menu cycle, or press NEXT to exit
the menu and return to the default cycle.
