SMP 300 Series • Remote Communication and Control 132
Command Function SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
Encoder Settings (Archive Encode and Recording) continued
Delayed Recording Start for Ad hoc
NOTE: The Mirroring LinkLicense is required in order to set the delay duration command.
Delay duration E
P
X59#
RCDR
}
Rcdr P
X59#] Delay ad hoc recording start for
X59#
seconds.
View delay duration E
PRCDR
} X59#] Query original setting.
View recording start
countdown
Example
RecStart
X59#]
RecStart12
]
,
RecStart11
]
,
RecStart10 ...
]
Unsolicited response to display
recording start countdown.
KEY:
X59#
= Delay duration in seconds 5 to 60 seconds (default = 5).
Recording Profiles
Recall recording profile E
R5*
X53)
PRST
}
PrstR5*
X53) ]
Query active profile E
L5PRST
}
PrstL5*
X53) ] Verbose 2/3 mode
View selected profile E
V5*
X53)
PRST
}
PrstV5*
X52( ] Verbose 2/3 mode
Delete recording profile
E
X5*
X53)
PRST
}
PrstX5*
X53)]
KEY:
X53)
= Presets 1 to 32 (two digit response — 0 padding)
X52(
= Json string of recording profile parameters (for example: [“id”:1,”name”;”RECORD PROFILE 01”, “contributor”:”Contributor1”,
“coverage”;”Coverage1”, Presentor1....})
Encoder Profile
Set profile E X50)
*
X4)
EPRO
}
Epro
X50)
*
X4) ]
Set encode profile to
X4)
.
View profile E X50)
EPRO
} X4) ]
View encode profile
X4)
.
Set output mode E
1*
X4!
SMOD
}
Smod1*
X4! ]
Set output mode to
X4!
.
View output mode E
1 SMOD
} X4!]
View output mode
X4!
.
KEY:
X4)
= Encode profile 1 = Base, 2 = Main, 3 = High
X4!
= Output mode 1 = Video and audio, 2 = Video only
X50)
= Stream selection 1 = Archive Channel A, 2 = Archive Channel B (Available for Dual Channel mode only)
3 = Confidence
Composite/Dual Channel Encoder Mode
Set archive encoding
mode
E
1*
X50#
ENCM
}
Encm 1*
X50#] Select encoding mode for
Archive.
View selected encoding
mode
E
1ENCM
} X50#]
View encoding mode for
Archive.
KEY:
X50#
= Encoding mode 0 = Composite mode, 1 = Dual Channel mode
Dual Channel HDMI Output
Set HDMI output E X6$
OMOD
}
Omod
X6$]
Set HDMI output to
X6$
.
Query HDMI output E
OMOD
} X6$ ]
KEY:
X6$
= HDMI output 0 = Channel A full screen, 1 = Channel B full screen, 2 = Confidence layout
