SMP 300 Series • Introduction 14
• Aspect ratio control — The aspect ratio of a source window can be controlled by
selecting a FILL mode, which provides a full screen output, FOLLOW mode, which
preserves the aspect ratio, or FIT mode, which maintains image uniformity and zooms
into the source.
• HDCP authentication and signal presence confirmation — Provides real-time
verification of HDCP status for each digital video input and output signal. This allows
for easy signal and HDCP verification through RS 232 or Ethernet, providing valuable
feedback to a system operator or helpdesk support staff.
• HDCP Visual Confirmation — When HDCP encrypted content is transmitted to a non
HDCP compliant display, a full screen green signal is sent to the display for immediate
visual confirmation that protected content cannot be viewed on that display.
• Quad standard video decoding — A digital, five-line adaptive comb filter decodes
NTSC 3.58, NTSC 4.43, PAL, and SECAM for integration into systems worldwide.
• Internal test patterns for setup — The SMP offers test patterns as well as on-screen
display - OSD data overlay including timestamp, number of connected users, CPU
usage, network status, disk free file space, audio level, and system information to aid in
calibration and setup.
• Front panel lockout — This feature locks out either all front panel functions, Menu
functions only, or all but recording transport controls. All functions are available through
Ethernet, USB, and RS 232 control.
• Ethernet monitoring and control — The SMP is controllable over Ethernet,
supporting configuration and real-time management from a control system.
• Embedded Web interface — Provide an intuitive Web interface with an embedded
video window for viewing the live stream, as well as source input and encoding
adjustments.
• RS-232 control port — Enable the use of serial commands for integration into
a control system. Extron products use the SIS - Simple Instruction Set command
protocol, a set of basic ASCII commands that allow for quick and easy programming.
• USB keyboard and mouse ports — Configure communication settings of the SMP
using a keyboard and mouse viewing the embedded webpage from the HDMI output
connection.
• LockIt HDMI cable lacing brackets included.
• Rack-mountable 1U, full rack width metal enclosure.
• Internal Extron Everlast power supply — Provides worldwide power compatibility,
with high demonstrated reliability and low power consumption for reduced operating
cost.
• Extron Everlast Power Supply is covered by a 7 year parts and labor warranty.
