SMP 300 Series • Installation 20
SMP 300 Series Reset Modes
Mode Activation Result Purpose and Notes
Factory Firmware
1 Hold in the recessed rear
panel Reset button while
applying power to the unit.
The SMP300 Series reverts to the
factory default firmware for a single
power cycle.
Use mode 1 to revert to
the factory default firmware
for a single power cycle if
incompatibility issues arise
with user-loaded firmware.
All user files and settings are
maintained.
NOTE: Do not operate with the default firmware loaded by a mode1 reset. Use it only to load the
most current firmware to the device.
Reset All IP Settings
*4
Hold in the Reset button
until the Reset LED blinks
twice (once at 3 seconds,
again at 6 seconds). Then,
release and press the
Reset button again within 1
second*.
Sets the following back to back to
factory default.
• Port mapping
• IP address: 192.168.254.254
• Subnet mask address:
255.255.0.0
• Gateway IP address: 0.0.0.0
Turns DHCP off.
The Reset LED on the rear panel
of the unit flashes four times in
succession.
Mode 4 is used to set
IP address information using
ARP and the MAC address.
Resetting IP Settings
appears on a connected
display.
Reset to Factory Defaults
*5
Hold in the Reset button
until the Reset LED blinks
three times (once at 3
seconds, again at 6 seconds,
again at 9 seconds). Then,
release and press the
Reset button again within 1
second*.
Performs a complete reset to factory
defaults (except the firmware).
• Does everything mode 4 does.
• Clears port configurations.
• Resets all IP options.
• Resets all passwords.
• Clears all user settings.
• Clears all files from the unit.
• The Reset LED on the rear panel
of the unit flashes four times in
succession.
Mode 5 is useful to start over
with default configuration and
uploading, and also to replace
events.
Resetting SMP300 Series
appears on a connected
display.
Mode 5 is equivalent to SIS
command ZQQQ (see SIS
command Absolute reset on
page116).
NOTES:
• *For modes 4 and 5, nothing happens if the momentary press does not occur within 1 second.
• The factory configured passwords for all accounts on this device have been set to the device serial
number. In the event of a complete system reset, the passwords convert to the default, which is no
password (see Users and Roles on page86 to change a password).
