Extron electronics SMP 300 Series User Manual

SMP 300 Series • Front Panel Operations 27
EXTRON
ELECTRONICS
2
sec.
EXTRON
SMP 35x FW V1.06
45
sec.
SMP 352
INITIALIZING
LOADING
FIRMWARE
30
sec.
~4
sec.
Power
On
Default Display Cycle
2
sec.
HH:MM:SS
TIME RECORD
2
sec.
2 sec.
In 1 1024x768@60
In 3 720p@60
2 sec.
CHA 5.0 MB
1280x720@30 fps
HH:MM:SS
TIME REMAIN
CHB 5.0 MB
1280x720@30 fps
2 sec.
2 sec.
Figure 14. Default Display Cycle for Dual Channel Mode
Press the MENU button once to bring up the first main (top level) menu, as shown below.
Each successive MENU button press cycles to the next main menu.
NOTE: From any menu or submenu, after 30 seconds of inactivity, the SMP300 Series
times‑out to the default display cycle.
1(;7
1(;7
1(;7
1(;7 1(;7
1(;71(;7
+
Input 5
for Edit Menu
1(;7
0(18
(to submenus) (to submenus) (to submenus) (to submenus)
(to submenus) (to submenus) (to submenus) (to submenus)
0HQX
0(180(18
0(18 0(18 0(18
0(18 0(18
INPUT
CONFIGURATION
ADVANCED
CONFIGURATION
VIEW COMM
SETTINGS
BACKGROUND
RECALL
CONTROL
PRESETS
RECORD/STREAM
CONFIGURATION
EXIT MENU?
PRESS NEXT
STATUS
(For Composite
Mode Only)
Figure 15. Top Level Menus
The flowchart above provides an overview of the menu system.
The top level menus are displayed one at a time, in order, on the LCD panel by pressing the
MENU front panel button.
To return to the default cycle from a top level menu or submenu, press MENU repeatedly until
EXIT MENU? shows, then press NEXT. Alternatively, the menu times out after 30seconds of
inactivity and returns to the default cycle.
Press NEXT when a menu displays to access its submenu. Within the submenu, press MENU
to exit the submenu and return to the currently active menu or press NEXT to move to the
next submenu.
Submenu details with configuration and options for each setting are on the following pages.
A complete schematic of the menus and submenus is in the reference section (see Front
Panel Menu Diagrams starting on page160).
14
15
