SMP 300 Series • Front Panel Operations 29
Default encoder presets
The first 18 encoder presets are predefined.
Preset 3 is the default value for the Archive Encoder (Channel A and Channel B).
Preset 9 is the default value for the Confidence Encoder (Streaming = on by default).
Preset
#
Preset Name Resolution Video
Bit Rate
(kbps)
Frame
Rate
(fps)
Audio
Bit Rate
(kbps)
Bit
Rate
Control
GOP
Length
H.264
Profile
H.264
Level
1
1080p High 1920x1080 8000 30 320 VBR 30 High
4.1
2
1080p Low 1920x1080 6000 15 128 CVBR 30 Main
3.2
*3
720p High 1280x720 5000 30 192 VBR 30 High
3.1
4
720p Low 1280x720 3000 15 128 CVBR 30 Main
3.1
5
480p High 848x480 2500 30 128 VBR 30 High
3.1
6
480p Low 848x480 1500 15 80 CVBR 30 Main
3.1
7
VGA High 1280x1024 3500 30 128 VBR 30 High
4.1
8
VGA Low 1024x768 2500 15 128 VBR 30 High
3.1
9
Confidence 512x288 350 15 192 VBR 15 Base
3.0
10
Speaker 1080p 1920x1080 5000 30 192 VBR 60 High
3.0
11
Speaker 720p 1280x720 2500 30 192 VBR 60 High
3.0
12
Speaker 480p 848x480 1000 30 192 VBR 60 Main
3.0
13
Presentation 1080p 1920x1080 2000 15 192 VBR 30 Main
3.0
14
Presentation 720p 1280x720 1000 15 192 VBR 30 Main
3.0
15
Presentation 480p 848x480 600 15 192 VBR 30 Main
3.0
16
Presentation
1440x180
1440x180 1600 15 192 VBR 30 Main
3.0
17
Presentation
1280x1024
1280x1024 1200 15 192 VBR 30 Main
3.0
18
Presentation
1024x768
1024x768 1000 15 192 VBR 30 Main
3.0
19‑32
User Defined
NOTES:
• *Audio settings are determined by the encoding for the primary recording or stream. Audio for confidence
monitoring is not re‑encoded. Therefore, by default, the recording uses encoder preset 3, and the audio bit
rate is 192 kbps.
• Default record mode is video and audio.
• The predefined encoder presets can be modified by the user. If necessary, a factory reset returns all changes
to the above table values.
User presets
User presets save current settings or recall previously saved configurations for the selected
input. User presets can be saved on one input rate and recalled on a different input rate.
There are 16 user presets per input.
User presets save the following parameters (per input):
• Color • Preset name
• Tint • Aspect ratio
• Contrast • Brightness
