SMP 300 Series • Front Panel Operations 31
The Channel Select submenu is available for all inputs. Subsequent picture control
submenus are available depending on the input selection (see the following table).
Range YUVp/
HDTV
YUVi Composite
Video
HDMI
Position
*
X X X
X
Size
Vert:64 to 4096
Horz:120 to 4096
X X X
X
Brightness
0 to 127
X X X
X
Contrast
0 to 127
X X X
X
Color
0 to 127
X X
Tint
0 to 127 NTSC Only
NOTES:
• * The position range depends on the selected resolution.
• X indicates applicable picture controls for the input type.
• The position and size values are for archive encoding.
Channel select
This submenu selects the input channel for the remainder of the submenus.
Rotate either ADJUST knob to select channel A and channel B.
Picture position (composite mode only)
This submenu sets the horizontal (H) and vertical (V) position of the active video for the
selected channel. The maximum value depends on the archive encoder resolution. The
range is dynamically adjusted to ensure at least 32x32 pixels of the window stay on the
screen. A small window (for example, 300 pixels wide) cannot go far into the negative (in this
case it is limited to ‑268 pixels).
To use this submenu:
• Rotate the left ([) ADJUST knob to change the horizontal position of the video for
the selected input. The selected value relates to the left edge of the active video. The
default is 0000.
• Rotate the right ({) ADJUST knob to change the vertical position of the video for the
selected input. The selected value relates to the top edge of the active video. The
default is 0000.
Picture size (composite mode only)
The Size submenu is used to set the horizontal and vertical size of the active video for the
selected input.
To use this submenu:
• Rotate the left ([) ADJUST knob to change the horizontal size of the video for the
selected input. The range of settings is dependent on the output resolution.
• Rotate the right ({) ADJUST knob to change the vertical size of the video for the
selected input. The range of settings is dependent on the output resolution.
