Programming manual
CNC 8055
CNC 8055i
AXES AND COORDINATE SYSTEMS
3.
·M· & ·EN· MODELS
SOFT: V02.2X
·41·
Axis nomenclature
3.1.1 Axis selection
Of the 9 possible axes that may exist, the CNC allows the manufacturer to select up to 7 of them.
Moreover, all the axes should be suitably defined as linear/rotary, etc. through the axis machine
parameters which appear in the Installation and Start-up Manual.
There is no limitation to the programming of the axes, and up to 7 axes may be interpolated at the
same time.
