Programming manual
CNC 8055
CNC 8055i
COORDINATE TRANSFORMATION
15.
·M· & ·EN· MODELS
SOFT: V02.2X
·433·
Movement in an inclined plane
15.1.5 Variables associated with function G49
Read-only variables associated with the definition of function G49
ORGROX ORGROY ORGROZ
New part zero coordinates with respect to home.
ORGROA ORGROB ORGROC
Values assigned to parameters A, B, C.
ORGROI ORGROJ ORGROK
Values assigned to parameters I, J, K.
ORGROQ ORGROR ORGROS
Values assigned to parameters Q, R, S.
GTRATY
Type of G49 programmed.
0 = no G49 has been defined.
1 = Type G49 X Y Z A B C
2 = Type G49 X Y Z Q R S
3 = Type G49 T X Y Z S
4 = Type G49 X Y Z I J K R S
Every time G49 is programmed, the CNC updates the values of the parameters that have been
defined.
For example when programming G49 XYZ ABC, the CNC updates the variables ORGROX,
ORGROY, ORGROZ, ORGROA, ORGROB, ORGROC. The rest of variables keep their previous
values.
Read-write variables updated by the CNC once function G49 is executed.
When having a swivel or angular spindle, general machine parameter XFORM (P93) with a value
of 2 or 3, the CNC shows the following data:
TOOROF
It indicates the position to be occupied by the spindle's main rotary axis in order to orient the spindle
perpendicular to the indicated inclined plane.
TOOROS
It indicates the position to be occupied by the spindle's secondary rotary axis in order to orient the
spindle perpendicular to the indicated inclined plane.
Accessing the variables TOOROF or TOOROS interrupts block preparation and the CNC waits for
that command to be executed before resuming block preparation.
