OBID i-scan
®
System-Manual ID ISC.MR/PR/PRH101
FEIG ELECTRONIC GmbH Page 38 of 131 H60301-3e-ID-B.doc
END-USR1...3 (from firmware version 1.03):
User defined end character.
HEADER-USR1...4 (from firmware version 1.03):
User defined Header character.
LEN-USR:
Defines the length of the HEADER character and END character.
Bit: 7 6 5 4 3 2 1 0
Function HEADER-LEN END-LEN
END-LEN
b0000 END-USR1
b0001 END-USR1
b0010 END-USR1 +2
b0011 END-USR1 + 2 + 3
HEADER-LEN
b0000 no HEADER byte
b0001 HEADER-USR1
b0010 HEADER-USR1 +2
b0011 HEADER-USR1 + 2 + 3
b0100 HEADER-USR1 + 2 + 3 + 4
Example of scan data:
COM-
ADR
Separation
Character
Header UID
Separation
Character
Data-
Blocks
END Character
COM-
ADR
SEP-CHAR USR1 USR2 USR3 USR4 UID SEP-CHAR DB USR1 USR2 USR3
