5. Parameter
5−24
Festo P.BE−CPX−CMAX−CONTROL−EN en 0908NH
Representation of the parameter entries
Cylinder length
PNU PNU: 1101 Index: 1 Max. index: 1 Class: Var Data type: int32
Values Unit: Length (index = 2)
Linear drive Semi−rotary drive
Dimen
sion
Default Minimum Maximum Dimen
sion
Default Minimum Maximum
SI 0.01 mm 0 0 1.000.000 0,1 ° 0 0 100.000
imperial 0.01 ft 0 0 1.000.000 0,1 ° 0 0 100.000
The cylinder length is stored in the sensor interface. Standard cylinders are not longer than
2,000 mm, the value range includes reserves for special applications.
When exchanging the drive, no projecting needs to be carried out as long as the specified cylinder
length deviates from the recognised cylinder length by no more
than 5.00 mm. This also allows
optimisation of the effective stroke.
ý The parameter value cannot be changed.
o Writing permissible only in commissioning/parametrising mode with disabled controller.
o This parameter can be written by FCT without higher−order controller.
o After writing, controller recalculation is carried out.
1 Name of the parameter
2 PNU (parameter number) with index, maximum index of the PNU, class and data
type
3 Parameter values:
For integer parameters (int32) with a physical unit, the unit and the values
(default, minimum, maximum) are specified for each system of measurement
(example).
For integer parameters (int32) without a physical unit, only default, minimum and
maximum values are specified.
With bitfields (bitarray), the default value is specified. It is also
specified which
bit can assume which value 0, 1 or x (any) during writing. With bitfields the CMA X
checks the status of the individual bits, not a value range.
Strings (char) are specified with their default values and the permissible charac
ters during writing.
4 Description of the parameter
5 Information about access restrictions and effects on the controller
Fig.5/4: Representation of the parameter entries
1
2
3
4
5
