Festo CPX-CMAX-C1-1 User Manual

5. Parameter
5−23
Festo P.BE−CPX−CMAX−CONTROL−EN en 0908NH
The overview contains the following entries
Index
Physical value
PNU Decimal parameter number
IND Subindex (Array, Struct) decimal (X = all or several subindexes of the PNU)
Max Max. index, largest index = array size/struct size
Class Parameter class (Var, Array, Struct)
Type Value type (int32, bitarray, char)
Unit Index of the physical unit (see PNU 1193 and section B.1)
RW Write permissions: R = read only, W = write only, RW = read and write
SH Higher−order controller (device control) required to make changes
IB Commissioning parameters, writing only in commissioning or parametrising mode
with disabled controller
NB Recalculation of the controller is performed after writing
UL Limit values are taken into account when making changes
Tab.5/15: Key on CMAX parameter overview
