5. Parameter
5−101
Festo P.BE−CPX−CMAX−CONTROL−EN en 0908NH
Start configuration
PNU PNU: 1195 Index: 1 ... 5 Max index: 5 Class: Struct Data type: int32
Values See description of the respective index.
Default: 0 Minimum: − Maximum: −
These are important configuration data at the time of adopting the serial numbers. The current con
figuration may only be modified within certain limits after this point in time.
Index Value Setpoint
configuration Unit Tolerance
1 Cylinder length PNU 1101 Length (index 2) 5.00 mm
2 Sensor length PNU 1111 Length (index 2) 5.00 mm
3 Sampling time 1 sec −
4 Mounting position PNU 1140 Mounting angle (index 12) 3°
5 Supply pressure PNU 1141 Pressure (index 4) 1 bar
ý The parameter value cannot be changed.
o Writing permissible only in commissioning/parametrising mode with disabled controller.
o This parameter can be written by FCT without higher−order controller.
o After writing, controller recalculation is carried out.
Notes on PNU 1195:
The actual configuration is
compatible: The actual configuration corresponds with
the setpoint configuration within the permissible limits.
Serial numbers may vary.
identical: The actual configuration corresponds with the
identification configuration within the permissible limits.
The serial numbers are identical.
If the configuration is not identical, warning W08 (component
exchanged) is
issued upon the first start. If it is not compat
ible, error message E01 (configuration error) is issued. The
application data is used to check whether certain changes
are permissible without resetting the identification data.
Only automatically recognized configuration data can be
compared to the setpoint configuration.
