A. Notes on commissioning and service
A−7
Festo P.BE−CPX−CMA X−CONTROL−EN en 0908NH
Description of the statuses
PNU 1192:02 = 0
Searching for valve and measuring system.
This process takes max. 3 seconds.
PNU 1192:02 = 0
The CMAX has found no setpoint configuration. The system
of measurement units has not yet been defined.
The user must first define the system of measurement units.
As long as no system of measurement units has been confi
gured, access to the axis parameters is restricted since the
CMAX does not know in
what way the parameters need to be
scaled. You only have access to diagnostic data and to data
required by the FCT to define the system of measurement
units (measuring system type etc.).
The system of measurement units is defined with
PNU 1192:05.
The following data can be accessed in this status:
PNU:IND
Access Description
1xx
2xx
Read/write Device data: define device names,
version numbers
Diagnostic data: read current
fault
1190:01
1190:05
1190:11
Read From hardware recognition:
cylinder type, sensor type, valve
type
1192:03 Read/write carry out data reset
1192:05
1192:06
Read/write
Read
System of measurement units
System of measurement units
table
Tab.A/1: Access to parameters in status C00
