9 Measurement
FLUXUS F60* 9.2 Measurement settings
101
UMFLUXUS_F60xV5-0EN, 2017-10-16
Function test
The function of the output can now be tested.
Connect an external measuring instrument to the terminals of the output.
Select yes to test the output.
Press ENTER.
Enter a test value for the selected physical quantity. If the external measuring instru-
ment displays the entered value, the output functions correctly.
Press ENTER.
Select yes to repeat the test.
Press ENTER.
9.2.5 Input of the error delay
The error delay is the time after which an error value will be sent to an output if no valid
measured values are available.
This display will only be indicated if the list item edit is selected in Special
Funct.\Dialogs/Menus\Error-val. delay.
If the error delay is not entered, the damping factor will be used.
Enter a value for the error delay.
Press ENTER.
Output Options\...\I1:Test output?
Output Options\...\I1:Test value=
Output Options\...\I1:Test output?
Example
output: current output
output range: 4…20 mA
Zero-Scale Val.: 0 m³/h
Full-Scale Val.: 300 m³/h
Test value = 150 m³/h (center of the measuring range, corresponds to 12 mA)
If the external measuring instrument displays 12 mA, the current output functions cor-
rectly.
Output Options\...\I1:Error-val. delay
