9 Measurement
FLUXUS F60* 9.3 Start of the measurement
103
UMFLUXUS_F60xV5-0EN, 2017-10-16
A deactivated channel will be ignored during the measurement. The parameters entered
for this channel will remain unchanged.
If the data logger or the serial interface is activated, the measuring point number has to
be entered:
Input of the measuring point number
• Enter the number of the measuring point.
• Press ENTER.
For the activation of text input, see Special Funct.\SYSTEM settings\Dialogs/
Menus\Meas.Point No.:.
Input of the sound path number
A value for the number of sound paths corresponding to the connected transducers and
the entered parameters is recommended.
• Change the value, if necessary.
• Press ENTER.
Adjustment of the transducer distance
The recommended transducer distance will be displayed.
• Mount the transducers on the pipe adjusting the transducer distance.
• Press ENTER.
– A - measuring channel
– Reflec - reflection arrangement
– Diagon - diagonal arrangement
The transducer distance is measured between the inner edges of the transducers.
In case of a measurement in diagonal mode on very small pipes, a negative transducer
distance is possible.
The diagnostics window is displayed, see Fig. 9.1.
Measuring\Channel\Meas.Point No.:
Measuring\Channel\...\Sound Path
Measuring\Channel\...\Transd. Distance
