17 Advanced functions
FLUXUS F60* 17.11 Activation of a binary output as alarm output
167
UMFLUXUS_F60xV5-0EN, 2017-10-16
17.11.2 Setting the limits
If the switching condition MIN or MAX is selected in the scroll list func, the limit of the out-
put has to be defined:
• Select the physical quantity to be used for the comparison in the scroll list Input. The
following list items are available for the alarm output R1:
– selected physical quantity
– signal amplitude
– sound speed of the fluid
• Press ENTER.
The current physical quantity is automatically set for the alarm outputs R2 and R3.
If the switching condition MAX is selected in the scroll list func, the limit of the output has
to be defined:
• Enter the upper limit.
• Press ENTER.
The alarm will switch if the measured value exceeds the limit.
If the switching condition MIN is selected in the scroll list func:
• Enter the lower limit.
• Press ENTER.
The alarm will switch if the measured value falls below the limit.
Notice!
If no measurement is made, all alarms will be de-energized, independently of the
programmed switching function.
R1 Input:\Mass Flow
R1 Input:\Function: MAX\High Limit:
R1 Input:\Function: MIN\Low Limit:
