17 Advanced functions
17.11 Activation of a binary output as alarm output FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
168
If the switching condition QUANT. is selected in the scroll list func, the limit of the output
has to be defined:
• Enter the limit of the totalizer.
• Press ENTER.
The alarm will switch when the measured value reaches the limit.
A positive limit will be compared to the totalizer value for the positive flow direction.
A negative limit will be compared to the totalizer value for the negative flow direction.
The comparison will also take place if the totalizer of the other flow direction is displayed.
Example
High Limit: -10 kg/h
mass flow rate = -9.9 kg/h
the limit is exceeded, the alarm switches
mass flow rate = -11 kg/h
the limit is not exceeded, the alarm does not switch
Example
Low Limit: -10 kg/h
mass flow rate = -11 kg/h
the measured value is below the limit, the alarm switches
mass flow rate = -9.9 kg/h
the measured value is not below the limit, the alarm does not switch
R1 Input:\Function: QUANT.\Quantity Limit:
Notice!
The unit of measurement of the limit is set according to the unit of measurement of
the selected physical quantity.
If the unit of measurement of the physical quantity is changed, the limit has to be
converted and entered again.
