9 Measurement
FLUXUS F60* 9.1 Parameter input
83
UMFLUXUS_F60xV5-0EN, 2017-10-16
9.1.1 Input of pipe parameters
Outer pipe diameter/pipe circumference
• Enter the outer pipe diameter.
• Press ENTER.
An error message will be displayed if the entered parameter is outside the range. The
limit is displayed.
Example: upper limit 1100 mm for the connected transducers and for a pipe wall thick-
ness of 50 mm.
It is possible to enter the pipe circumference instead of the outer pipe diameter, see sec-
tion 19.1.
If the input of the pipe circumference is activated and zero is entered in Outer Diame-
ter, the menu item Pipe Circumfer. will be displayed. If the pipe circumference is
not to be entered, press key BRK to return to the main menu and start the parameter in-
put again.
Wall thickness
• Enter the pipe wall thickness.
• Press ENTER.
Parameter\Outer Diameter
The inner pipe diameter (= outer pipe diameter - 2 × pipe wall thickness) will be cal-
culated internally.
If the value is not within the inner pipe diameter range of the connected transducers,
an error message will be displayed.
It is possible to change the lower limit of the inner pipe diameter for a given trans-
ducer type, see section 17.10.
Parameter\Wall Thickness
To Next Page
