9 Measurement
FLUXUS F60* 9.2 Measurement settings
95
UMFLUXUS_F60xV5-0EN, 2017-10-16
9.2.3.1 Output of the measured value
When configuring an analog output, the output range is defined.
• Select Special Funct.\SYSTEM settings\Proc. outputs\...\I1 Output
range.
• Press ENTER.
Output range
• Select a list item.
– 4/20 mA
– other range...
• Press ENTER.
If other range... is selected, enter the values Output MIN and Output MAX.
• Press ENTER after each input.
Error output
In the following dialog, an error value can be defined which is output in case a source
item cannot be measured, e.g., if there are gas bubbles in the fluid.
• Select a list item for the error output, see Tab. 9.2.
• Press ENTER.
•If Other value... is selected, enter an error value. The value has to be within the
output range.
• Press ENTER.
Source item
Output range
Error-value
active loop
Output Test
see annex A, p. 224
Special Funct.\SYSTEM settings\Proc. outputs\...\I1 Output range
Special Funct.\SYSTEM settings\Proc. outputs\...\I1 Error-value
