9 Measurement
9.2 Measurement settings FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
94
Temperature is only available if a temperature input has been assigned to the channel
Tfluid ← (Ti)*
fluid temperature measured by the temperature
probe at the point where the flow is measured
Taux S/R ← (Ti)*
fluid temperature measured by the other tem-
perature probe
Tsupply ← (Ti)* supply temperature
Treturn ← (Ti)* return temperature
Ts-Tr ← (Ti-Tj)* difference supply temperature-return
temperature
Tr-Ts ← (Ti-Tj)* difference return temperature-supply
temperature
T(3) ← (Ti)* 3rd temperature input of the measuring
channel
T(4) ← (Ti)* 4th temperature input of the measuring
channel
* i, j: number of the assigned temperature input
Pulse from abs(x) pulse without sign consideration
from x > 0 pulse for positive measured values
from x < 0 pulse for negative measured values
Miscellaneous c-Medium sound speed of the fluid
SCNR ratio useful signal to correlated disturbance
signal
Signal signal amplitude of a measuring channel
VariAmp standard deviation of the signal amplitude
Density density of the fluid
Pressure pressure of the fluid
Tab. 9.1: Configuration of outputs
source item list item output
