Flexim FLUXUS F60 Series User Manual

9 Measurement
FLUXUS F60* 9.2 Measurement settings
93
UMFLUXUS_F60xV5-0EN, 2017-10-16
Tab. 9.1: Configuration of outputs
source item list item output
Measuring value actual measure physical quantity selected in the program
branch Output Options
Flow flow, independently of the physical quantity se-
lected in the program branch Output Op-
tions
Heatflow heat flow, independent of the physical quantity
selected in the program branch Output Op-
tions
Quantity Q+ totalizer for the positive flow direction
* actual measure totalizer for the physical quantity selected in
the program branch Output Options
* Flow flow totalizer
* Heatflow heat flow totalizer
Q– totalizer for the negative flow direction
* actual measure totalizer for the physical quantity selected in
the program branch Output Options
* Flow flow totalizer
* Heatflow heat flow totalizer
ΣQ sum of the totalizers (positive and negative
flow direction)
* actual measure totalizer for the physical quantity selected in
the program branch Output Options
* Flow flow totalizer
* Heatflow heat flow totalizer
Limit R1 limit message (Alarm Output R1)
R2 limit message (Alarm Output R2)
R3 limit message (Alarm Output R3)
