9 Measurement
9.2 Measurement settings FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
92
Selection of an output
• Select the output to be installed.
• Press ENTER.
The scroll list contains all available outputs of the transmitter:
– Current IX (--)
– Binary BX (--)
– Frequency FX (--)
A tick () after a list item indicates that this output has already been installed.
• Select yes to install or reconfigure the output.
• Press ENTER.
• Select no to uninstall the output and to return to the previous menu item in order to se-
lect another output.
• Press ENTER.
Assignment of a measuring channel
• Select the measuring channel to be assigned to the output as the source channel in the
scroll list.
• Press ENTER.
Assignment of a source item
One source item has to be assigned to each selected output.
• Select the physical quantity (source item) to be transmitted to the output by the source
channel.
• Press ENTER.
If a binary output is configured, only the list items Limit and Impuls will be displayed.
The source items and their scroll lists are described in Tab. 9.1.
Special Funct.\SYSTEM settings\Proc. outputs\Install Output
Special Funct.\SYSTEM settings\Proc. outputs\I1 enable
Special Funct.\SYSTEM settings\Proc. outputs\...\I1 Source chan.
Special Funct.\SYSTEM settings\Proc. outputs\...\Source item
