9 Measurement
FLUXUS F60* 9.2 Measurement settings
91
UMFLUXUS_F60xV5-0EN, 2017-10-16
9.2.3 Installation of an output
If the transmitter is equipped with outputs, they have to be installed and activated before
they can be used:
• assignment of a measuring channel (source channel) to the output
• assignment of the physical quantity (source item) to be transmitted to the output by the
source channel, and the properties of the signal
• definition of the output behavior in case no valid measured values are available
• activation of the installed output in the program branch Output Options
In the following, the configuration of an analog outputs is described.
• Select Special Funct.\SYSTEM settings\Proc. outputs.
• Press ENTER.
SYSTEM settings
Proc. outputs
Install Output
enable
Source chan.
Source item
see annex A, p. 224
The settings will be stored at the end of the dialog. If the menu item is quit by press-
ing key BRK, the changes will not be stored.
Special Funct.\SYSTEM settings\Proc. outputs
