Page #98 background image
9 Measurement
9.2 Measurement settings FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
98
Terminal assignment
The terminals for the connection of the output are displayed.
Press ENTER.
If the transmitter possesses a switchable current output, it is displayed whether it is ac-
tive or passive (here: active).
Output function test
The function of the output can now be tested.
Connect an external measuring instrument to the terminals of the output.
Enter a test value. It has to be within the output range.
Press ENTER.
If the external measuring instrument displays the entered value, the output functions cor-
rectly.
Select yes to repeat the test, no to return to the menu item SYSTEM settings.
Press ENTER.
Special Funct.\SYSTEM settings\Proc. outputs\...\I1 active loop
Special Funct.\SYSTEM settings\Proc. outputs\...\I1 Output Test
Special Funct.\SYSTEM settings\Proc. outputs\...\
I1= 10 mA\Again?
