Flowserve Limitorque QX Maintenance And Spare Parts

35
Limitorque QX Electronic Actuator FCD LMENIM3314-01 – 06/18
flowserve.com
4.5 Pipe Plug
NOTE: Sections 4.2 – 4.8 require the actuator to be removed from the mounting plate and the oil drained.
Table 4.14 - Pipe Plug
ITEM NUMBER DESCRIPTION QTY.
12-1 PIPE PLUG 1
Figure 4.17 Pipe Plug
NOTE:
If the pipe plug was removed, pipe sealant or tape must be applied to plug threads before remounting.
4.6 Baseplate
4.6.1 Baseplate Removal
NOTE: Sections 4.2 – 4.8 require the actuator to be removed from the mounting plate and the oil drained.
NOTE: If unit has a F/FA-05 or 07 QX-1 & 2, F/FA-10 QX-3 thru 5 base or Thrust base attached, these bases must be
removed before removing the standard baseplate. See section 4-9 thru 4-10.
12-1
12-1
