Dynamic Data Exchange (DDE)
DDE Example Using Excel
G
G-3
3. Select cell A1 on the spreadsheet, move the cursor to the Formula Bar and
enter the remote reference formula to link cell A1 to instrument 25 channel
13, then <Enter>. (See below.)
Type the formula and then <Enter>
Item (channel number)
Exclamation Point
Topic (instrument BCN)
Equal Sign
Service Name
Pipe Character
Select cell A1
If the instrument is scanning, measurement data is displayed in cell A1.
4. In the same manner, select cell A2 and enter formula
=NETDAQ32|bcn25!’c14’ <Enter>; then select cell A3 and enter formula
=NETDAQ32|bcn25!’c15’ <Enter>.
