FOR-A MFR-3000 User Manual

83
 Setting Function Parameters
Function
Parameter
Note
(NONE)
DEST
DEST:XXX
(XXX: Destination channel number)
LEVEL:XXXX
(XXXX: Level)
SRC
SRC:XXXX
(XXXX: Source channel number)
LEVEL:XXXX
(XXXX: Level)
BUS
DEST:XXX
(XXX: Destination channel number)
SRC:XXXX
(XXXX: Source channel number)
LEVEL:XXXX
(XXXX: Level)
PAGE
MODE:JUMP
(JUMP: Jump to a specified page
/UP : Go forward a page
/DOWN: Go back a page)
PAGE:XX
(XX: Page number)
* Effective for
JUMP
RETPAGE:XX
(PREV PAGE: Return to the previous page /XX:
Jump to the next specified page)
* Effective for
JUMP
GROUP-A:ON
(ON / OFF)
GROUP-B:ON
(ON / OFF)
GROUP-C:ON
(ON / OFF)
GROUP-D:ON
(ON / OFF)
MODE
DESTINATION:ON
(ON / OFF)
SOURCE :ON
(ON / OFF)
LEVEL :ON
(ON / OFF)
PAGE_Grp-All:ON
(ON / OFF)
PAGE_Grp-A :ON
(ON / OFF)
PAGE_Grp-B :ON
(ON / OFF)
PAGE_Grp-C :ON
(ON / OFF)
PAGE_Grp-D :ON
(ON / OFF)
SETTING :ON
(ON / OFF)
LOCK
LOCK[S]:OTHER
(NONE / OTHER / ALL / LOCAL)
LOCK function by short press
DEST:XX
(CURRENT: Locks the current destination.
/ XX: Destination Channel number to be locked)
* Effective for
OTHER and ALL
LOCK[L]:NONE
(NONE / OTHER / ALL / LOCAL)
LOCK function by long press
DEST:XX
(CURRENT: Locks the current destination.
/ XX: Destination Channel number to be locked)
* Effective for
OTHER and ALL
TAKE
LEVEL
LEVEL:XXXX
(XXXX: Level)
LINK
TENKEY
SKIP
MODE:FWD
(FWD: Forward / BWD: Backward)
COUNT:XXX
(XXX: number of channels to skip)
MON-OUT
OUT :X
(X:MONITOR OUT)
* MFR-5000/
8000 only
O-PREVIEW
DEST:XXX
(XXX: Destination channel number)
SALVO
MODE:MU RECALL
(MU RECALL: Execute the main unit-assigned
SALVO
/RU RECALL: Execute the button-assigned
SALVO
/RU STORE: Assign a SALVO to a button)
NO:XXXX
(XXXX: Salvo number)
* Effective for
MU RECALL,
and RU RECALL
