5.4 Details of Function Codes
5-143
Details of
Function Codes
F codes
E20 to E27
C codes
P codes
H codes
A codes
b codes
r codes
J codes
d codes
U codes
y codes
Chapter 5 Function Code
Data Control Method
Active
ON
Active
OFF
Defined Functions Signal Name
V/f
PG
V/f
PG
Less
PG
Torque
Control
Related
Function
Code/
Related Signal
(Data)
37 1037 Current detected ID
{ { { { {
38 1038 Current detected 2 ID2
{
{
{ { {
39 1039 Current detected 3 ID3
{
{
{ { {
41 1041 Low current detected IDL
{
{
{ { {
E34
, E35,
E37, E38,
E55, E56
42 1042 PID alarm output PID-ALM
{
{
{ {
X J11 to J13
43 1043 Under PID control PID-CTL
{
{
{ {
X J01
44 1044 PID small water amount stopping PID-STP
{
{
{ {
X J08, J09
45 1045 Low torque detected U-TL
{ { { { {
46 1046 Torque detected 1 TD1
{
{
{ { {
47 1047 Torque detected 2 TD2
{
{
{ { {
E78 to E81
48 1048 Motor 1 switched SWM1
{
{
{ { {
49 1049 Motor 2 switched SWM2
{
{
{ { {
50 1050 Motor 3 switched SWM3
{
{
{ { {
51 1051 Motor 4 switched SWM4
{
{
{ { {
A42, b42,
r42
52 1052 Running forward signal FRUN
{
{
{ { {
―
53 1053 Running reverse signal RRUN
{
{
{ { {
―
54 1054 In remote mode RMT
{ { { { {
(See Section
3.3.6.)
56 1056 Thermistor detection THM
{
{
{ { {
H26, H27
57 1057 Brake signal BRKS
{
{
{ {
X J68 to J72
58 1058 Frequency (speed) detected 3 FDT3
{ { { { {
E32, E54
59 1059 C1 terminal wire break detected C1OFF
{
{
{ { {
―
70 1070 Speed valid DNZS X
{ { { {
F25, F38
71 1071 Speed agreed DSAG X
{ { {
X d21, d22
72 1072 Frequency (speed) arrival 3 FAR3
{ { { {
X E30
76 1076 PG error detected PG-ERR X
{
{ {
X d21 to d23
77 1077 Low and medium voltage detected U-EDC
{ { { { {
E76
78 1078
Momentary power failure
decelerating
IPF2
{ { { { {
E76
82 1082 Positioning completion signal PSET XXX
{
X J97 to J99
84 1084 Maintenance timer MNT
{ { { { {
H44
, H78,
H79
90 1090 Alarm details 1
A
L1
{ { { { {
91 1091 Alarm details 2
A
L
2
{ { { { {
92 1092 Alarm details 4
A
L4
{ { { { {
93 1093 Alarm details 8
A
L
8
{ { { { {
98 1098 Light alarm L-ALM
{
{
{ { {
H81, H82
99 1099 Batch alarm
A
L
M
{
{
{ { {
―
105 1105 Braking transistor broken DBAL
{
{
{ { {
H98
111 1111 Customizable logic output signal 1 CLO1
{ { { { {
112 1112 Customizable logic output signal 2 CLO2
{ { { { {
U71 to U75,
U81 to U85
