5.4 Details of Function Codes
5-158
E44
LED Monitor (Display When Stopped)
This function selects the monitoring information displayed by the keypad LED while the inverter is at stop.
When E44 = 0, the set frequency is displayed, and when E44 = 1, output frequency is displayed. The display
form is as selected in the speed monitor E48.
Table 5.4-83
While Stopping
E48 Data
Monitor
Selection
E44 = 0: Displays the set
frequency
E44 = 1: Displays the output
frequency
0
Output
frequency 1
(before slip
compensation)
Set frequency
Output frequency 1
(before slip compensation)
1
Output
frequency 2
(after slip
compensation)
Reference frequency
Output frequency 2
(after slip compensation)
2
Set frequency Set frequency Set frequency
3
Rotation speed Rotation speed set value Rotation speed
4
Loaded rotation
speed
Loaded rotation speed set
value
Loaded rotation speed
5
Line speed Line speed set value Line speed
7
Speed (%) Speed set value Speed
E48
Details of LED Monitor (Speed Monitor Selection) (See E43)
For details of the LED monitor (speed monitor selection), see the section describing the function code E43.
