5.4 Details of Function Codes
5-159
Chapter 5 Function Code
Details of
Function Codes
F codes
E44 to E49
C codes
P codes
H codes
A codes
b codes
r codes
J codes
d codes
U codes
y codes
E49
Torque Monitor (Polarity Select)
When using the calculated torque of V/f control and torque command value of the vector control, generally,
the driving side of the torque polarity is at positive, and the braking side is at negative. When the rotation
changes from normal to inverse by the lifting load, etc., the torque also changes from the driving side to the
braking side, and the polarity inverses. When the torque data is traced by the PC loader, the polarity of the
torque command value changes, and the data do not become the consecutive data. When 0 is selected for
this function code, the forward drive and reverse braking are handled at positive, and forward braking and
reverse braking are handled as negative. Therefore, the continuity of the torque data can be secured.
Table 5.4-84
E49 Data Torque Monitor Polarity
0 Torque polarity (forward drive and reverse braking are +, forward braking and reverse drive are -.)
1 Drive is +, Brake is - (default value)
Related data are as follows. All of these are displayed or transferred with the polarities. Judge the meanings
of signs by using the set values of E49.
Table 5.4-85
Monitor, Output Data Setting Related Data
E43 = 8
Calculated torque
Isolated keypad / Multi-purpose keypad LED
monitor
E43 = 23
Torque current
Isolated keypad / Multi-purpose keypad
Operation monitor
3_04
Calculated torque
Isolated keypad / Multi-purpose keypad
Alarm data
6_03 Torque calculated value in alarm (Latest value to the
third value from the latest one)
OPC-G1-AIO
o71 = 4
*
Output torque
M02
Torque command (latest command)
M03
Torque current command (latest command)
M07
Output torque
M08
Torque current
M28
Torque command in alarm (latest command)
M29
Torque current command in alarm (latest command)
M33
Output torque in alarm
M34
Torque current in alarm
W07
Torque actual value
W24
Torque current
X23
Latest data in alarm (calculated torque value)
X63 One data before the latest one in alarm (calculated
torque value)
Z03 Two data before the latest one in alarm (calculated
torque value)
Z53 Three data before the latest one in alarm (calculated
torque value)
Monitor code
Z81
Output torque
* When the terminal Ao (polarity select) (o73) setting is 0: only in case of both polarity, the output data of
E49 polarity is obtained.
