Chapter 5 Function Code
E52
Keypad Menu Select
With the function code E52 setting, displaying menu can be limited.
Table 5.4-86
E52 Data Mode Menus to be Displayed
0
Function code data setting mode Menu #0, Menu #1, Menu #7
1
Function code data check mode Menus #2, Menu #7
2
Full-menu mode Menu #0 through Menu #7
Selects the menu to be displayed on the standard keypad. Eight menus available on the standard keypad
are described below.
Table 5.4-87
Menu #
LED Monitor
Display
Function Display Contents
0
*fnc
Quick setup Quick setup function code
1
!f__
Data setting F to o F to o group function code
2
"rep
Data check Changed function code
3
#ope
Operation monitor Operation status display
4
$i_o
I/O check DIO, AIO status display
5
%che
Maintenance Maintenance information display
6
&al
Alarm information Alarm Information display
7
'cpy
Data copy Data copy operation type
For the menu contents, see "Chapter 3 Keypad Functions."
E54
Frequency Detection 3 (Operation Level) (See E31)
For details, see the description of E31.
E55, E56
Current Detection 3 (Operation Level, Timer) (See E34)
For setting of current detection 3 (operation level) and current detection 3 (timer), see the description of E34.
