App. G Replacement Information
A-33
App.
FRENIC5000G9S/P9S FRENIC-MEGA
Class
Terminal Signal Name Terminal Signal Name
Y1 Transistor output 1 Y1 Transistor output 1
Y2 Transistor output 2 Y2 Transistor output 2
Y3 Transistor output 3 Y3 Transistor output 3
Y4 Transistor output 4 Y4 Transistor output 4
Y5 Transistor output 5 Y5A, Y5C
General-purpose relay
output
CME Transistor output common CMY Transistor output common
(RUN) Running RUN Running
(FAR)
Frequency (speed) arrival
signal
FAR
Frequency (speed) arrival
signal
(FDT) Frequency (speed) detected FDT
Frequency (speed)
detected
(LU) Undervoltage detected LU Undervoltage detected
(TL) Torque limiting IOL Inverter output limiting
(RES)
Auto-restarting after
momentary power failure
IPF
Auto-restarting after
momentary power failure
(OL)
Motor overload early
warning
OL
Motor overload early
warning
(KP) Keypad operation enabled KP Keypad operation enabled
(STP) Inverter stopped RUN
Inverter running (negative
logic setting)
Pattern operation stage
transfer
-
Pattern operation 1 cycle
completion
-
Pattern operation stage No.
1
-
Pattern operation stage No.
2
-
Pattern operation stage No.
4
-
Trip factor display signal 1 -
Trip factor display signal 2 -
Trip factor display signal 4 -
Trip factor display signal 8 -
Transistor output
(TRY) Auto-resetting TRY Auto-resetting
30A, 30B, 30C Alarm relay output 30A, 30B, 30C Alarm relay output
Contact
output
AX1, AX2
Power supply side contactor
open command
(30 kW or above)
(Y5A, Y5C) AX AX terminal function
