2.2 Wiring
2-27
Chapter 2 INSTALLATION AND WIRING
Analog output, pulse output, transistor output, and relay output terminals
Table 2.2-16
Classification
Symbol Name Functional description
[FMA] Analog monitor
(FMA function)
The monitor signal
for analog DC voltage (0 to +10 V) or analog
DC current (+4 to +20 mA or 0 to +20 mA *4) is output. You can
select the output form (VO/IO) by switching the slide switch SW4
on the control PCB and changing data of the function code F29.
You can select one of the following signal functions with function
code F31.
• Output frequency • Output current • Output voltage
• Output torque • Load factor • Power consumption
• PID feedback amount
• Speed (PG feedback value) • DC link bus voltage
• Universal AO • Motor output • Analog output test
• PID command • PID output
• Angular deviation (synchronous mode)*3
*
Input impedance of the external device: Min. 5
kΩ (at 0 to
10VDC output)
(While the terminal is outputting 0 to 10 VDC, it is capable of
driving up to two analog voltmeters with 10
kΩ impedance.)
* Input impedance of the external device: Max. 500
Ω (at 4 to
20 mA DC output)
* Adjustable range
of the gain: 0 to 300%
Analog output
[11] Analog common
Two common terminals for analog input/output signals
These terminals are electrically isolated from terminals [
CM]s
and [CMY].
