1.2 Part Names and Functions
Network Scanner fi-6000NS Operator's Guide 5
Scanner Overview
1
1.2.2 Internal Parts
No. Part name Function
1
Pad assembly Help to guide documents from the ADF paper chute to the
glass scanner windows.
2
Pick roller
3
Sheet guide
4
Glass scanner win-
dows
Place where the documents are scanned.
5
ADF (Automatic Doc-
ument Feeder)
Drives the documents from the ADF paper chute, past the
glass scanner windows, to the output tray.
1. Pad assembly
2. Pick roller
3. Sheet guide
Separate
shaft and roller
4. Glass scanner windows
5. ADF
