3.5 Using the System Settings Menus
Network Scanner fi-6000NS Operator's Guide 63
Administrator Operations
3
3.5.7 Setting the Multifeed Detection Method
By default, multifeed detection will monitor for paper overlaps in the central column (width:
35mm) of the document being scanned. However, any photos or attachments in this area will also
be detected as a multifeed.
When scanning documents, multifeed detection area may be adjusted to ignore the area (excluding
the photograph or attachments) and prevent mis-detections.
For document requirements for multifeed detection, refer to "A.5 Multifeed Detection Conditions"
(page 328).
1. Select the [System Settings] tab on the top menu.
2. Press the [Down] button on the left side menu.
⇒ Scroll the left side menu down until the [Multifeed Settings] tab appears.
3. Select the [Multifeed Settings] tab on the left side menu.
⇒ The "Multifeed Settings" screen appears.
To Next Page
