Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

15.7 Dual microSD 64GB Enterprise 317
15.7.1 Installing the Dual microSD 64GB Enterprise 317
15.7.2 Removing the Dual microSD 64GB Enterprise 319
15.7.3 Replacing the Dual microSD 64GB Enterprise 321
15.7.4 Replacing the microSD card 323
15.8 System board 325
15.8.1 Replacing the system board 325
16 Appendix A
335
16.1 Mechanical overview 335
16.1.1 Server front 335
16.1.1.1 2.5-inch HDD/SSD configuration 335
16.1.1.2 3.5-inch HDD configuration 336
16.1.2 Server rear 336
16.1.2.1 Server rear with standard PSU 336
16.1.2.2 Server rear with hot-plug PSUs 337
16.1.3 Server interior 338
16.2 Connectors and indicators 342
16.2.1 Connectors and indicators on the system board 342
16.2.1.1 System board D3675 342
16.2.2 Server front 346
16.2.2.1 Indicators on the front panel 346
16.2.2.2 Indicator on the ODD 350
16.2.2.3 Indicators on the hot-plug HDD/SSD module 351
16.2.3 Server rear 352
16.2.3.1 Connectors on the server rear 352
16.2.3.2 ID, CSS and Global Error indicators 353
16.2.3.3 LAN indicators 355
16.2.3.4 Indicator on hot-plug PSU 357
16.2.3.5 Indicator on FJBU 358
16.2.4 Acoustic indicators 359
16.3 Onboard settings 361
16.4 Minimum startup configuration 362
Content
RX1330 M4 Upgrade and Maintenance Manual

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
