GE Giraffe - Figure 5-9 Elevating Base with Three-Piece Shroud Assembly

Main bracket casting
Back cover
Elevating column
Bed up/down pedal switch
Caster
Column power cable
Lower mounting plate
Outer column
Lower shroud
Upper shroud
Figure 5-9 Elevating Base with Three-piece Shroud Assembly
© 2001 by Datex-Ohmeda, Inc.. All rights reserved. 6600-0356-000 103 77
Chapter 5: Repair Procedures
