4.4.21 System Failure 26
System failure 26 indicates: During the power up tests, the system was unable to turn o safety relay 1.
Cause(s) Action(s)
Defective relay board. Replace the relay board.
4.4.22 System Failure 27
System failure 27 indicates: Defective non-volatile memory.
Cause(s) Action(s)
Defective circuit on control board. Replace the control board.
4.4.23 System Failure 28
System failure 28 indicates: During operation, the display driver board lost communication with control board.
Cause(s) Action(s)
Refer to system
failure 0.
Power down the unit, during the self-test the unit should detect system failure 0.
Follow the instructions for system failure 0 in section 4.4.1.
Defective at ribbon
cable between
control board and
display board.
If system failure 28 persists without system failure 0, replace the at ribbon cable
between control board and display board.
4.4.24 System Failure 29
System failure 29 indicates: Defective signal on control board.
Cause(s) Action(s)
Defective control board Replace the control board.
