Humidier Fuse
Time Lag 3.15A/250V
6600-0517-602
(The interface board
plugs into these clips.)
Supply Fuse
Time Lag 3.15A/250V
6600-0517-602
Humidier Interface Board
No longer needed.
Fuse 120V 2 amp
6600-1324-602
Fuse 230V 1 amp
6600-1324-601
#
Board assembly revision
number
Figure 6-35 Relay Board (6600-0214-850) Revision Level 9 or Lower
