GE Giraffe - Sensor Housing Temperature Sensor Temperature to Resistance Curve

4.7.3.4 Sensor Housing Temperature Sensor Temperature to Resistance Curve
Temperature Resistance
15C 15.720 kohm
25C 10.000 kohm
30C 8.056 kohm
35C 6.530 kohm
40C 5.326 kohm
45C 4.369 kohm
50C 3.604 kohm
60C 2.491 kohm
64 6600-0356-000 103 © 2001 by Datex-Ohmeda, Inc.. All rights reserved.
Chapter 4: Troubleshooting
