GE Giraffe - PCB Layouts; Figure 6-32 Control Board (6600-0212-850)

6.4 PCB Layouts
Main control board software (U42)
6600-0234-850*
Audio software (U22)
6600-0243-850
Audio wave form (U18)
6600-0244-850
Calibration Jumper
6600-1226-600
REV:
Control board
revision level number
*Kit includes display driver software.
Figure 6-32 Control Board (6600-0212-850)
