6.1.3 Hood and Compartment Air Probe
1. Compartment air probe@ .............................................6600-1512-700
Probe harness cable@ ....................................................6600-1513-700
2. O-ring ......................................................................................6600-0540-400
3. Humidity sensor assembly*..........................................6600-0784-700
Plug (no humidity sensor installed) ...........................6600-1476-500
4. Retainer ..................................................................................6600-1475-500
5. Break plate ...........................................................................6600-1473-500
6. Screw, M3 x 6 button hd .................................................6600-0706-406
7. Probe shield ..........................................................................6600-1864-500
8. Back plate .............................................................................6600-1474-500
9. Flat washer, M3...................................................................6600-0712-402
10. Split ring lock washer ......................................................6600-0713-402
11. Screw, M3 x 25 button hd ..............................................6600-0706-450
12. Screw, M4 x 16 button hd ..............................................6600-0706-411
13. Cable clamp .........................................................................6600-0144-400
14. Lock nut, M4 ........................................................................6600-0714-402
15. Hinge snap ...........................................................................6600-1436-500
16. Hinge post .............................................................................6600-1848-500
17. Hood latch kit ......................................................................6600-0231-850
Parts not shown
Humidier Calibration Kit* ............................................6600-0048-850
Hood replacement kit (includes hood,
4 each of items 15 and 16, 10 each of
item 14, 2 each of item 4 and 4 each of
item 15 shown on previous page, and labels)
Ventilator slot and porthole ..........................................6600-0232-850
Ventilator slot and iris porthole ..................................6600-0270-850
Ventilator slot and ventilator slot ...............................6600-0269-850
Oscillator (High Freq. Vent) port cover .....................6600-0838-800
* Unit must be recalibrated using Humidier Calibration Kit whenever sensor is replaced.
@ For earlier units with a compartment air probe cable that disconnected at the probe panel, order service kit 6600-0241-850.
114 6600-0356-000 103 © 2001 by Datex-Ohmeda, Inc.. All rights reserved.
Chapter 6: Illustrated Parts
