1. Using a 2.5 mm hex key, loosen the 2 screws in the keyhole slots and remove the 6 remaining screws that
secure the controller cover, then remove the cover. Disconnect the wire harnesses coming from the probe
panel.
2. Remove the 2 screws at the bottom corners that hold the probe panel to the enclosure.
3. Remove the probe panel assembly.
4. While tilting the panel enclosure forward, use a 3mm hex key to remove the 4 screws that hold the panel
frame in place. Add new jacks through the panel frame as appropriate.
NOTE: The power switch panel must be on the far left. The position of the remaining panels is not critical.
5.8.2.1 Battery
The battery snaps into a holder on the side of the probe panel housing. It has two snap connectors at its top.
When replacing the battery, its easier to rst connect the terminals then push the battery into its holder.
NOTE: Run the unit for at least two hours to charge the new battery before using the unit. The battery charges
only when the unit is powered on.
NOTE: If your battery is in the electrical enclosure above the relay board, order relocation kit M1045981.
This kit includes parts and instructions to relocate the battery to the probe panel to reduce battery ambient
temperature and prolong battery life.
