6.1.5 Humidier

1. Flat washer, M3 x 3.2, ID .5 ............................................6600-0712-402

2. Split ring lock washer, M3 x 3.1, ID .8 ........................6600-0713-402

3. Screw, M3 x 16 Cheese head Phillips ........................6600-1255-404

4. Reservoir switch (included in item 21)

5. Button, reservoir switch .................................................6600-1298-500

6. Top humidier gasket ......................................................6600-1293-500

7. Heater mount ......................................................................6600-1291-500

8. Screw, M3 x 8 Cheese head Phillips,

Teon coated .......................................................................6600-1255-401

9. Ramp block ..........................................................................6600-1777-500

10. Humidier gasket bottom .............................................6600-1294-500

11. Protective insert .................................................................6600-1714-500

12. Reservoir seal ......................................................................6600-1495-500

13. Insulating cylinder .............................................................6600-1182-500

14. Bottom bracket ..................................................................6600-1181-500

15. Steam outlet ........................................................................6600-1296-500

16. Silicone tube ........................................................................6600-1780-500

17. Heater sheath* ...................................................................6600-1292-500

18. Nut, hex 6 -32 .....................................................................0144-3324-113

19. Split ring lock washer, #6 ...............................................6600-0345-400

20. Safety thermostat assembly ........................................6600-0225-850

21. Add water thermostat assembly

(includes item 4) .................................................................6600-0803-700

22. Humidier heater* ............................................................6600-0224-850

23. Spacer, .125 ID ....................................................................6600-1779-500

24. Humidier top bracket ....................................................6600-1295-500

25. Star washer, M3 x 3.2 ID .................................................6600-0713-442

26. Screw, M3 x 12 Cheese head Phillips ........................6600-1255-403

27. Humidier reservoir ..........................................................6600-0216-850

Reservoir bottom ...............................................................6600-1493-500

Reservoir lid ..........................................................................6600-1492-500

28. Screw, M3 x 10 skt. hd. ....................................................6600-0707-403

29. Screw, M3 x 10 Cheese hd.

Phillips Teon coated .......................................................6600-1255-402

Parts not shown

Humidier heater kit

(includes all parts above except reservoir) .....................6600-0245-850

* Always replace item 17 when replacing item 22.

Chapter 6: Illustrated Parts

GE Giraffe Service Manual
