4. Using a 4 mm hex key, remove the button head socket screws on either side of the pedal switch.
5. Disconnect the switch electrical connector and pull the switch out. Discard old bed up/down pedal switch.
6. Install new bed up/down pedal switch. Make sure that you do not pinch the electrical wires.
80 6600-0356-000 103 © 2001 by Datex-Ohmeda, Inc.. All rights reserved.
Chapter 5: Repair Procedures
