1. Rear Cover ............................................................................6600-1134-500
2. Screw, M3 x 8 Button Head ...........................................6600-0706-405
3. Washer, M3 Split Ring ......................................................6600-0713-402
4. Washer, M3 Flat ..................................................................6600-0712-402
5. Stando, M3 x 2.25” .........................................................6600-1070-400
6. PCA Display Driver ............................................................6600-0213-850
7. Stando, M3 x 2.0” ............................................................6600-1068-400
8. EL Display Harness ...........................................................6600-0725-700
9. Display Cage ........................................................................6600-0222-850
10. Round Spacer ......................................................................6600-1191-400
11. Rotary Encoder Switch
(includes cable, lockwasher, and nut).......................6600-1026-600
12. ESD Cage* .............................................................................6600-1133-500
13. Nut Plate ................................................................................6600-1276-500
14. No longer available.
15. Touch Panel Assembly ....................................................6600-1254-600
16. Screw, M2.5 x 8 Socket Head .......................................6600-0715-403
17. Alarm Lens ............................................................................6600-1132-500
18. Right (east) Seal ..................................................................6600-1736-501
19. Control knob ..........................................................................6600-1480-500
20. Power Fail Lens ...................................................................6600-1065-400
21. Display Bezel ........................................................................6600-1131-500
22. Left (west) Seal ....................................................................6600-1736-502
23. Light Pipe ...............................................................................6600-1066-400
24. Washer, M4 Flat ..................................................................6600-0712-403
25. Washer, M4 Split ring .......................................................6600-0713-403
26. Screw, M4 x 10 Socket Head ........................................6600-0707-409
27. Nut, M3 ...................................................................................6600-0711-403
28. PCA LED ..................................................................................6600-0215-850
29. LED Display Harness ........................................................6600-0739-700
30. Washer, M3 Internal lock ...............................................6600-0713-431
*When replacing, must also order touch panel (6600-1254-600).
102 6600-0356-000 103 © 2001 by Datex-Ohmeda, Inc.. All rights reserved.
Chapter 6: Illustrated Parts
