1. Power supply* .....................................................................6600-0221-850
Mounting hardware-
Spacer, M3 x 8 .....................................................................6600-1192-400
Star washer, M3 ..................................................................6600-0713-442
Nut, M3 ...................................................................................6600-0711-403
2. Nut, M3 ...................................................................................6600-0711-403
3. Star washer, M3 ..................................................................6600-0713-442
4. Nut, M4 ...................................................................................6600-0711-407
5. Split ring washer, M4 ........................................................6600-0713-403
6. Washer, M4 ...........................................................................6600-0712-403
7. Humidier isolation transformer ................................6600-1328-600
8. Spacer, M3 x 18 ..................................................................6600-1192-400
9. Screw, M6 skt. hd. ..............................................................6600-0707-420
10. Lockwasher, M6 int. tooth .............................................6600-0713-434
11. Mounting bracket ..............................................................6600-1587-500
12. Washer. M4 ...........................................................................0402-1133-300
13. Nylon lock nut, M4 ............................................................6600-0714-402
14. Lockwasher, M3 ext. tooth ............................................6600-0713-442
15. Nylon lock nut, M3 ............................................................6600-0714-401
16. Wire harness. ISO transformer ....................................6600-1526-700
17. Screw, M4 x 6 .......................................................................6600-0706-407
18. Lockwasher, M4 int. tooth .............................................6600-0713-432
19. Cable twist lock ..................................................................6600-1197-600
20. RS232 chassis .....................................................................6600-1479-500
21. Screw lock, female ............................................................6600-0673-400
22. Retaining clip .......................................................................6600-0672-400
23. Wire harness (with 9 pin D connector) ....................6600-1531-700
24. RS232 ThermaLink PC board .......................................M1059915
RS232 upgrade kit .............................................................6600-0257-850
25. Wire harness (connects to Control PCB) .................6600-1530-700
*The fuses on the power supply cannot be replaced. If the fuses are open there will be component damage that necessitates replacing
the entire power supply.
106 6600-0356-000 103 © 2001 by Datex-Ohmeda, Inc.. All rights reserved.
Chapter 6: Illustrated Parts
