GE Giraffe - 6.5 Wiring Diagrams; Wiring Diagram: Control Board

1. End cap, top left (West) ..................................................6600-1799-500
2. End cap, top right (East) ..................................................6600-1800-500
3. Speed nut ..............................................................................0402-2003-300
4. Screw, M4 ..............................................................................6600-0708-409
5. Decorative strip (teal) .......................................................6600-1456-501
6. End cap, bottom right (East) .........................................6600-1463-500
7. End cap, bottom left (West) ...........................................6600-1341-500
8. Cord wrap .............................................................................6600-1482-500
Dog point set screw .........................................................6600-1124-400
9. Routing clips (6) ..................................................................6600-0055-851
10. Screw, M4 ..............................................................................6600-0707-408
11. Star washer ..........................................................................6600-0713-432
12. Ground wire .........................................................................6600-0883-700
13 Upright, left (West) ............................................................6600-0280-850
14. Upright, right (East) ...........................................................6600-0280-851
128 6600-0356-000 103 © 2001 by Datex-Ohmeda, Inc.. All rights reserved.
Chapter 6: Illustrated Parts
