1. Screw, M4x12L Skt Hd .....................................................6600-0707-410
2. Split ring washer, M4 ........................................................6600-0713-403
3. Valve housing top cover .................................................6600-1838-500
4. Valve housing wire harness ..........................................6600-1069-700
5. Adapter 1/8NPTFx1/8NPTM..........................................6700-0616-800
6. Elbow tting 10 OD x1/8NPT ........................................6600-0873-400
7. Screw, M4 Skt Hd ...............................................................6600-1051-400
8. Flat washer, M5...................................................................6600-0712-409
9. Damper manifold mount ...............................................6600-1248-400
10. Valve housing ......................................................................6600-1836-500
11. Valve housing bottom cover ........................................6600-1837-500
12. Jam nut, M14 ......................................................................6600-0711-450
13. Label Max kPa .....................................................................6600-2448-101
Label Max PSI ......................................................................6600-2448-102
14. Lock washer, M14 Int tooth ...........................................6600-0713-438
15. Push-in tting, 90° Elbow ...............................................6600-0865-400
16. Supply valve .........................................................................6600-0602-700
17. Manifold .................................................................................6600-1839-500
plug ..........................................................................................0413-3510-335
gasket .....................................................................................6600-1950-500
18. Regulator assembly .........................................................6600-0254-850
In-line screen tting .........................................................6600-1249-400
19. O2 adapter, Air Liquide ....................................................6600-0725-400
20. O2 adapter, DIN ..................................................................6700-0050-700
21. O2 adapter, NIST ................................................................6600-0100-400
22. O2 adapter, DISS ................................................................6700-0522-800
23. Washer, M4 ...........................................................................6600-0712-403
Parts not shown
Oxygen inlet label (green) .......................................................6600-2611-101
Oxygen inlet label (white) ........................................................6600-2611-102
Valve housing assembly (includes
all parts above except items 11, 13
and mounting hardware) ...............................................6600-1507-700
6mm Tubing (order by inch) ..........................................6600-0866-400
From regulator to manifold, 3.9”
Tubing/sleeve assembly .................................................6600-0262-850
10mm tube from valve housing
to expansion chamber, 27”
132 6600-0356-000 103 © 2001 by Datex-Ohmeda, Inc.. All rights reserved.
Chapter 6: Illustrated Parts
